specs
Compression format H.265 Pro +, H.265 Pro, H.265, H.264 +, H.264
Supports coaxitron connection
32 BNC inputs
2 IP 5MP inputs
Expandable IP inputs up to 18 by canceling analog channels
VGA (1080P) and HDMI (1080P) outputs
Two-way audio: 1 RCA input / 1 RCA output
Recording resolution: 5MP (IP), 1080N, 720P, 720N, WD1, 4CIF, VGA, CIF, QVGA
Main stream in 1080P mode: 1080N, 720N, WD1, 4CIF, VGA (15 ips), CIF (25 ips)
Main stream in 720P mode: 720P, WD1, 4CIF, VGA (15 ips), CIF (15 ips)
Secondary stream: CIF, QVGA (15 ips)
16-channel synchro playback
Supports 1 channel line crossing and intrusion detection
Smart search
Supports multiple video analytics events from smart IP and analog cameras
Internal capacity for 2 SATA HDDs up to 10TB (sold separately)
Self-adaptive RJ45 (10/100 / 1000M) Ethernet network interface
Network protocols: TCP / IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP ™, HTTPS
ONVIF compliant
Remote access for up to 128 users
Connections: 1 USB 2.0 port, 1 USB 3.0 port
Power supply: 12V DC
Consumption: ≤18W
Operating temperature: -10 ° C ~ + 55 ° C
Relative humidity: 10 ~ 90%
Dimensions: 380 x 320 x 48 mm
Weight: 2.2 kg
