specs
16 IP camera inputs
H.265 + / H.265 / H.264 + / H.264 / MPEG4 encoding
Incoming bandwidth: 160 Mbps
Outgoing bandwidth: 80 Mbps
Video output VGA 1080P and HDMI 4K
Two-way audio: 1 RCA input / 1 RCA output
Recording resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Synchronized playback of up to 16 channels
1ch 8MP or 4ch 1080P real-time decoding capability
Video and audio stream
2 HDD capacity up to 6TB (HDD not included)
Self-adaptive RJ45 (10/100 / 1000M) Ethernet network interface
Network protocols: TCP / IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP ™, HTTPS
Connections: 2 USB 2.0
Power supply: 100V ~ 240V AC
The rear panel incorporates 16 PoE + ports (IEEE 802.3 at / af)
Consumption (without hard drives): ≤15W
Maximum consumption (with PoE): ≤280W
-10 ° C ~ + 55 ° C operating temperature
Relative humidity: 10 ~ 90%
Dimensions: 385 x 315 x 52 mm (desktop, 1U)
Weight: ≤2.6 kg
