specs
8-channel IP NVR H.265 + / H.265 / H.264 + / H.264 / MPEG4 format
8 IP camera inputs
Incoming bandwidth: 80 Mbps
Outgoing bandwidth: 80 Mbps
HDMI (4K) and VGA (1080P) video output
Two-way audio: 1 RCA audio input / 1 output
Display / Playback Resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
Recording resolution: 8MP, 6MP, 5MP, 4MP, 3MP, 1080P, UXGA, 720P, VGA, 4CIF, DCIF, 2CIF, CIF, QCIF
8-channel synchro playback
1 ch 8MP at 25 ips or 4 ch 1080P at 25 ips
Capacity for 1 HDD up to 6TB (HDD not included)
Self-adaptive RJ45 (10/100 / 1000M) Ethernet network interface
Network protocols: TCP / IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP ™, HTTPS
Connections: 2 USB 2.0
Power supply: 48V DC
NVR consumption: ≤10W
The rear panel incorporates 8 PoE + ports (IEEE 802.3 at / af)
Maximum PoE consumption: ≤75W
Operating temperature: -10 ° C ~ + 55 ° C
Relative humidity: 10 ~ 90%
Dimensions: 315 x 240 x 48 mm (1U)
Weight: ≤1 kg
