Specifications
1/2.7" 2 megapixel CMOS sensor
Digital resolution: 1080P (1920x1080), 720P (1280x720), 960H (960x756)
Frames per second: 25 fps @1080P (CVI/TVI/AHD), 25 fps @720P (CVI/TVI/AHD), 50 fps @720P (CVI/TVI)
4-in-1 output switchable via OSD or via DAHUA-498 UTC controller (PFM820)
Day/Night mode with removable mechanical filter (ICR)
0.02 lux F1.9 (colour) / 0 lux IR On
Smart IR: 12 leds, up to 20 metres
2.8 mm fixed optics
Viewing angle: 101°(H), 54°(V), 119°(D)
OSD via coax (1080P video up to 800 metres, 720P up to 1200 metres).
Picture modes: BLC, HLC, digital WDR, 2D-NR, digital Defog, Mirror.
Automatic and manual white balance
Automatic and manual gain control
Supports 8-zone privacy masking
Power supply: 12V DC (±30%)
Power consumption: 3.2W (max.)
Storage temperature -40°C ~ +60°C (-40°C ~ +60°C)
Operating temperature from -40°C ~ +60°C
Relative humidity: <95% (non-condensing)
Degree of protection IP50
Indoor installation environment
Plastic housing
Dimensions: Ø85.4 x 70.2 (H) mm
Weight: 130 g
3AXIS: 0°~360°(PAN), 0°~78°(TILT), 0°~360°(Rotation)
